Descripción
Voltaje de alimentación: 12 a 24 Vdc, rango mínimo y máximo 10-32Vdc
Corriente máxima de Salida: 200mA
Corriente de consumo: 10mA
Alcance: 8mm
Tipo de Salida: 3 Hilos con conector
-B modelo: PNP open Collector
-C modelo: NPN open Collector
Respuesta en frecuencia: 800HZ
VER FICHA TÉCNICA
| Especificaciones | E2A-M12KN08-M1-B1 | E2A-M12KN08-M1-B2 | E2A-M12KN08-M1-C1 | E2A-M12KN08-M1-C2 |
|---|---|---|---|---|
| Size | M12 | M12 | M12 | M12 |
| Mounting type | Non-flush | Non-flush | Non-flush | Non-flush |
| Sensing distance | 8 mm | 8 mm | 8 mm | 8 mm |
| Output type | PNP | PNP | NPN | NPN |
| Operation mode | NO | NC | NO | NC |
| Connection method | Connector M12 | Connector M12 | Connector M12 | Connector M12 |
| Material housing | Brass, nickel plated | Brass, nickel plated | Brass, nickel plated | Brass, nickel plated |
| Cable specifications | – | |||
| Overall length of sensor | 48 mm | 51 mm | 51 mm | 51 mm |
| Thread length | 27 mm | 24 mm | 24 mm | 24 mm |
| Features | Gold plated connector pins | |||
| Degree of protection (IP) | IP67 | IP67 | IP67 | IP67 |
